The CW50R is a 2-way coaxial in-wall system. The CW50R has been carefully optimized for a neutral and well balanced sound quality.
The 5.25-inch woofer with a fiberglass textured polypropylene cone has high power handling, smooth response and extended bandwidth. The 3/4‚¬? tweeter has a 2 piece diaphragm and suspension for low resonance and low distortion. The tweeter has a pivoting mount to allow it to be aimed towards the listener‚¬„s location for most extended response.
‚¬œDog leg‚¬? style mounting clips ensure quick and easy mounting.
In-wall loudspeakers must deal with limited space within the confines behind the wall. Wall cavities are not built to any standard volume so open back in-wall speakers must work within a wide range of wall cavity volumes. PSB accomplishes this by giving the woofers higher mass and stiffness than with conventional ‚¬œin room‚¬? enclosures. Extensive simulations and testing have shown that our designs deliver high-performance sound quality with a broad range of wall cavity volumes. The CW50R can be used with the CWS8 subwoofer/ CWA-1 subamplifier combination.
Full 2nd order high-pass and low-pass crossover filtering is used to enhance system power handling and give enough control in the design process to achieve a smooth and very well balanced sound. It is a perfect match to any other PSB product.
- 5-1/4‚¬? woofer with stiff fiberglass textured polypropylene cone, higher cone mass and enhanced motor strength to optimize it to a restricted enclosure volume
- Low resonance 3/4 inch pivoting
- High power drivers and crossover for long term
- Performance Enclosure and new construction bracket available
Frequency Range (-6dB): 65-20,000Hz Recommended Power: 20-60 Watts Impedance (Nominal): 8 Ohms Sensitivity (2.83V @1m) 86dB SPL Drivers: 5-1/4‚¬? Woofer
3/4‚¬? Dome Tweeter
Overall Dimensions (Diameter x D): 7-13/16 diameter x 2-15/16‚¬? Cut-out Dimensions (Diameter): 6-1/2‚¬?
All eligible company warranty and service support is being provided on PSB CW50R - PAIR IN-CEILING 5.25" SPEAKER CUSTOM SOUND
